Product Details:
|
| Weight: | 4.1kg | Voltage: | 110V/220V |
|---|---|---|---|
| Condition: | New | Driven Type: | Electric |
| Packaging Type: | Cartons | Power: | 18W |
| Warranty: | 1 Year | Function: | Strip Labels |
| Product Name: | Automatic Label Dispenser | Labeling Speed: | 130mm/c |
| Dimension(l*w*h): | 166(W)*174(H)*280(D)mm | ||
| High Light: | Electric Label Dispenser 220V,Electric Label Dispenser 50HZ,Industrial label stripping machine |
||
industrial Automatic Label Dispenser machine Sticker 220V 50HZ Label stripping machine electric label dispenser X-130
1. Function:
1) Ideal for small labels and small work areas
2) Will dispense label and die-cut parts
3) Photosensor Accuracy and Reliability
4) Automatically removes paper,vinyl,acetate,polyester,foil,etc.from its liner
5) Automatically rewinds liner scrap for acleaner working environment
6) No tools required for adjusting to different size labels
7) No maintenance required
8) High torque motor for large diameter label rolls
9) Feature:LCD counter can show how many labels has been dispensed
| Dimensions | 166(W)*174(H)*280(D)mm |
| Feed Speed | 130mm/C |
| Available Lable Width | 5-130mm |
| Roll Capacity | 250mm in dia |
| Lable Material | Any material can be used |
|
speed
|
130mm/sec |
Wrapped the Lable on the hanging board as the picture shows and fix with positioning plate.
Insert the guide plate,then insert the label into between the label delivery board and the middle stick,shows U shape shape,then adjust the guide board according to the label width.
Please hange the label into the roll paper device,open the upper device and put the label into the 3 sticks of roll paper device.
Open the power switch which behind right direction.
When the machine in stripping labels,please get the labels from the buttom up.
Wrapped the Lable on the hanging board as the picture shows and fix with positioning plate.
Insert the guide plate,then insert the label into between the label delivery board and the middle stick,shows U shape shape,then adjust the guide board according to the label width.
Close the Interlock lever,press the paper press plate button till hear the clocked alarming.
Open the power switch which behind right direction.
When the machine in stripping labels,please get the labels from the buttom up.
1.OEM Manufacturing is welcome.
2. Sample order is accepted.
3. We will reply you for your inquiry within 24 hours.
4. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solution for you.
5. The warranty of our products is 1 year.
FAQ
Q1. What is your packaging terms?
Usually, we package our products in color boxes and brown cartons. Provide a reasonable minimum order quantity of OEM services. If you have a legally registered patent, we can package the item into your brand box after receiving your authorization. The cost depends on the quantity.
Q2. How is your delivery time?
In general, the number of 100 sets or less is only 2-10 working days. The exact delivery time depends on the model of the material, the stock of the material and the quantity of the order.
Q3. What is your sample policy?
We do not have a minimum order quantity for sample orders. And the sample order can enjoy the fastest lead time only one day after receiving the payment.
Q4. Do you test all the goods before delivery?
Yes, we performed 100% testing before delivery and all products were tested for at least 48 hours to ensure good quality.
Q5. How do you make our business a long-term and good relationship?
1. We maintain good quality and competitive prices to ensure customer benefits;
2. We respect each customer as our friend, we do business in good faith, make friends with them,
No matter where they come from
